HPI5P-AT pH/Ion Meter

HPI5P-AT pH/Ion Meter

General Features

  • Color High contrast LCD touchscreen, 4.3 inches.
  • Intelligent operation system provides features including user management, calibrationmanagement, electrode management, method management, data management, LogManagement and etc.
  • Multi-reading feature allows auto-read, timed-read and continuous-read.
  • Automatic/Manual temperature compensation ensures accurate results.
  • Auto-hold feature senses and locks the measurement endpoint.
  • Data Storage 1000 sets for each parameter (GLP-compliant).
  • Data analysis feature helps user review, compare and recalculate results.
  • Support for USB communication.
  • Auto-power off feature effectively extends the battery service life.
  • Reset feature automatically resumes all settings back to factory default options.
  • IP65 waterproof. The portable meter is suitable for fields measurements and out door measurements.

Ion

  • 1-8 points calibration.
  • Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc.
  • Multi-measurement modes are supported, including Direct Reading mode, Standard Addition mode, Sample Addition mode and GRAN mode.

pH

  • 1-8 points calibration with Standard Recognition.
  • Selectable pH buffer groups, including USA, NIST, DIN, GB, MERK, JIS.
  • User-defined pH buffer or buffer group is supported.
  • Automatic electrode diagnosis with pH slope and offset display.

Share with friends

Description

Model PH500T
Parameters pH/Temp.(mV/ORP)








pH

 Range -2.000 to 20.000 pH
Resolution 0.1, 0.01, 0.001pH
Accuracy ± 0.002 pH
Calibration Points Up to 6
Standard Customization Yes
Calibration Reminder Yes
Standard Recognition NIST, GB, DIN, USA, MERK, JIS buffers
Slope Limit Yes




mV/ORP

 Range -2000.00 to 2000.00 mV
Resolution 0.1, 0.01 mV
Accuracy ± 0.1 mV or ± 0.03%
EH ORP Mode Yes
ORP Calibration Points 1 custom point (relative mV)


Temperature

 Range -10 to 135 ºC, 14 to 275 ºF
Unit ºC, ºF
Resolution 0.1
Accuracy ± 0.1


Measurement

 Reading Mode Auto Read (Fast, Medium, Slow), Timed, Continuous
Reading Prompts Reading, Stable, Locked
Temp. Compensation ATC, MTC


Data management

 Data Storage 1000 Groups
GLP Features Yes
Log Management Yes
Inputs pH Electrode BNC(Q9)
Temp. Probe 4-pin aviation connector
Outputs USB USB 2.0 flash memory device, PC, scanner
RS 232 printer, auto-sampler


Display options

 Backlight Yes
Auto Shutdown 1~60 min, off
IP Rating IP54
Date and Time Yes


General

 Power AC Adapter, 100-240V AC input, DC24V output
Dimensions 220 × 195 × 68 mm
Weight 950g (2.09 lb)
